View Large Image
| View Original: | XB-70A_#1_liftoff_with_TB-58A_chase_aircraft.jpg (1536x1321) | |||
| Download: | Original | Medium | Small | Thumb |
| Courtesy of: | www.flickr.com | More Like This | ||
| Keywords: aviation aerospace national aeronautics and space administration nationalaeronauticsandspaceadministration nasa airplane aircraft bomber north american aviation northamericanaviation naa north american b-70 valkyrie northamericanb70valkyrie north american b-70 northamericanb70 north american valkyrie northamericanvalkyrie b-70 valkyrie b70valkyrie north american xb-70 valkyrie northamericanxb70valkyrie north american xb-70 northamericanxb70 xb-70 valkyrie xb70valkyrie north american xb-70a valkyrie northamericanxb70avalkyrie north american xb-70a northamericanxb70a xb-70a valkyrie xb70avalkyrie b-70 b70 b-70a b70a xb-70 xb70 xb-70a xb70a valkyrie general electric generalelectric ge general electric j93 generalelectricj93 ge j93 gej93 general electric yj-93 generalelectricyj93 ge yj-93 geyj93 j-93 j93 yj-93 yj93 af 62-0001 af620001 62-0001 620001 convair b-58 hustler convairb58hustler convair b-58 convairb58 convair hustler convairhustler b-58 hustler b58hustler tb-58 tb58 ge j-79 gej79 j-79 j79 convair tb-58 convairtb58 convair tb-58a convairtb58a tb-58a tb58a armstrong afrc nasa armstrong nasaarmstrong vehicle outdoor airliner jet jetliner jumbo jet Description: This photo shows XB-70A #1 taking off on a research flight, escorted by a TB-58 chase plane. The TB-58 (a prototype B-58 modified as a trainer) had a dash speed of Mach 2. This allowed it to stay close to the XB-70 as it conducted its research maneuvers. When the XB-70 was flying at or near Mach 3, the slower TB-58 could often keep up with it by flying lower and cutting inside the turns in the XB-70's flight path when these occurred. The XB-70 was the world's largest experimental aircraft. It was capable of flight at speeds of three times the speed of sound (roughly 2,000 miles per hour) at altitudes of 70,000 feet. It was used to collect in-flight information for use in the design of future supersonic aircraft, military and civilian. The major objectives of the XB-70 flight research program were to study the airplane's stability and handling characteristics, to evaluate its response to atmospheric turbulence, and to determine the aerodynamic and propulsion performance. In addition there were secondary objectives to measure the noise and friction associated with airflow over the airplane and to determine the levels and extent of the engine noise during takeoff, landing, and ground operations. The XB-70 was about 186 feet long, 33 feet high, with a wingspan of 105 feet. Originally conceived as an advanced bomber for the United States Air Force, the XB-70 was limited to production of two aircraft when it was decided to limit the aircraft's mission to flight research. The first flight of the XB-70 was made on September 21, 1964. The number two XB-70 was destroyed in a mid-air collision on June 8, 1966. Program management of the NASA-USAF research effort was assigned to NASA in March 1967. The final flight was flown on February 4, 1969. Designed by North American Aviation (later North American Rockwell and still later, a division of Boeing) the XB-70 had a long fuselage with a canard or horizontal stabilizer mounted just behind the crew compartment. It had a sharply swept 65.6-percent delta wing. The outer portion of the wing could be folded down in flight to provide greater lateral-directional stability. The airplane had two windshields. A moveable outer windshield was raised for high-speed flight to reduce drag and lowered for greater visibility during takeoff and landing. The forward fuselage was constructed of riveted titanium frames and skin. The remainder of the airplane was constructed almost entirely of stainless steel. The skin was a brazed stainless-steel honeycomb material. Six General Electric YJ93-3 turbojet engines, each in the 30,000-pound-thrust class, powered the XB-70. Internal geometry of the inlets was controllable to maintain the most efficient airflow to the engines. UID: SPD-NIX-ED97-44244-2 Date: February 4, 1969 Description: This photo shows XB-70A #1 taking off on a research flight, escorted by a TB-58 chase plane. The TB-58 (a prototype B-58 modified as a trainer) had a dash speed of Mach 2. This allowed it to stay close to the XB-70 as it conducted its research maneuvers. When the XB-70 was flying at or near Mach 3, the slower TB-58 could often keep up with it by flying lower and cutting inside the turns in the XB-70's flight path when these occurred. The XB-70 was the world's largest experimental aircraft. It was capable of flight at speeds of three times the speed of sound (roughly 2,000 miles per hour) at altitudes of 70,000 feet. It was used to collect in-flight information for use in the design of future supersonic aircraft, military and civilian. The major objectives of the XB-70 flight research program were to study the airplane's stability and handling characteristics, to evaluate its response to atmospheric turbulence, and to determine the aerodynamic and propulsion performance. In addition there were secondary objectives to measure the noise and friction associated with airflow over the airplane and to determine the levels and extent of the engine noise during takeoff, landing, and ground operations. The XB-70 was about 186 feet long, 33 feet high, with a wingspan of 105 feet. Originally conceived as an advanced bomber for the United States Air Force, the XB-70 was limited to production of two aircraft when it was decided to limit the aircraft's mission to flight research. The first flight of the XB-70 was made on September 21, 1964. The number two XB-70 was destroyed in a mid-air collision on June 8, 1966. Program management of the NASA-USAF research effort was assigned to NASA in March 1967. The final flight was flown on February 4, 1969. Designed by North American Aviation (later North American Rockwell and still later, a division of Boeing) the XB-70 had a long fuselage with a canard or horizontal stabilizer mounted just behind the crew compartment. It had a sharply swept 65.6-percent delta wing. The outer portion of the wing could be folded down in flight to provide greater lateral-directional stability. The airplane had two windshields. A moveable outer windshield was raised for high-speed flight to reduce drag and lowered for greater visibility during takeoff and landing. The forward fuselage was constructed of riveted titanium frames and skin. The remainder of the airplane was constructed almost entirely of stainless steel. The skin was a brazed stainless-steel honeycomb material. Six General Electric YJ93-3 turbojet engines, each in the 30,000-pound-thrust class, powered the XB-70. Internal geometry of the inlets was controllable to maintain the most efficient airflow to the engines. UID: SPD-NIX-ED97-44244-2 Date: February 4, 1969 | ||||
