| View Original: | Negative resistance oscillator load lines.svg (947x569) | |||
| Download: | Original | Medium | Small | Thumb |
| Courtesy of: | commons.wikimedia.org | More Like This | ||
| Keywords: Negative resistance oscillator load lines.svg negative resistance oscillator showing load lines It consists of a negative differential resistance such as a Gunn diode connected across a resonant circuit A voltage source V<sub>bias</sub> biases the diode into its negative resistance region where it has resistance Δv/Δv -r The negative resistance cancels the positive resistance R in the circuit exciting oscillations i t DCL is the DC load line which establishes the Q point SSL is the small signal load line which is the operating condition when the oscillator first starts up and oscillations have a small amplitude As the oscillations grow the nonlinearity of the diode eventually limits the amplitude The sine wave extends into nonlinear regions near the edges of the negative resistance region where the negative resistance is smaller so the average negative resistance decreases until it is equal to the load resistance R shown by LSL the large signal load line The nonlinearity distorts the output sine wave at large amplitudes 2012-12-20 18 01 50 own Chetvorno cc-zero Uploaded with UploadWizard Negative resistance Device current-voltage characteristics | ||||
