| Keywords: Fiberline Bridge Kolding Denmark 2013c.JPG en Fiber Line Bridge is one of the world's largest fiberglass composite bridges and the first to cross a railway line which increases the requirements for the bridge It is located in Kolding Denmark The bridge was built in 1997 as a collaboration between the Municipality of Kolding FiberLine Composites and Rambøll It is Scandinavia's first composite bridge The bridge weighs 12 tonnes which is half of a bridge in metal / concrete Another of the advantages of fiberglass composite is that it is almost maintenance-free Since its construction in 1997 there have only been removed graffiti and algae The bridge is also not affected by rain frost and salt Lifespan is at least 100 years Technical data Length total 40 m Length bridge section 1 27 m Length bridge section 2 13 m Width total 3 2 m Tower height 18 5 m Total weight 12 tons Capacity 500 kg/m2 Capacity running load 5 tons Maximum wheel pressure 1 8 tons The maximum deflection L/200 13 cm Number stag 8 da Fiberline-broen er en af verdens største glasfiber-kompositbroer og den første der krydser en jernbanelinje hvilket øger kravene til broen Den ligger i Kolding Danmark Broen blev opført i 1997 som et samarbejde mellem Kolding Kommune Fiberline Composites og Rambøll Det er Skandinaviens første kompositbro Broen vejer kun 12 tons hvilket er det halve af en bro i metal/beton En anden af fordelene ved glasfiber-komposit er at den er næsten vedligeholdelsesfri Siden opførelsen i 1997 er der kun blevet fjernet graffiti og alger Broen påvirkes heller ikke af regn frost eller salt levetid er mindst 100 år Tekniske data Længde total 40 m Længde brosektion 1 27 m Længde brosektion 2 13 m Bredde total 3 2 m Tårn højde 18 5 m Totalvægt 12 tons Bæreevne 500 kg/m2 Bæreevne kørende last 5 tons Maksimum hjultryk 1 8 tons Maksimum nedbøjning L/200 13 cm Antal stag 8 2013-09-26 12 25 32 own S Juhl 55 4999 9 50949 cc-zero Bridges in Denmark Bridges in Kolding Uploaded with UploadWizard | ||||
