| View Original: | F-8_Digital_Fly-by-Wire_(DFBW)_in_flight_over_snow_capped_mountains_DVIDS692994.jpg (1536x1321) | |||
| Download: | Original | Medium | Small | Thumb |
| Courtesy of: | commons.wikimedia.org | More Like This | ||
| Keywords: F-8 Digital Fly-by-Wire (DFBW) in flight over snow capped mountains DVIDS692994.jpg en F-8 Digital Fly-by-Wire DFBW aircraft in flight over snow capped mountains Externally identical to a standard Navy F-8C this aircraft had its control system replaced initially by a primary system using an Apollo digital computer The backup system used three analog computers When the pilot moved the airplane's stick and rudder electronic signals went to the computer which would generate signals to move the control surfaces The system was designed so that the digital fly-by-wire aircraft would handle almost identically to a standard F-8C Later in Phase 2 the aircraft used three IBM AP-101 computers for its flight control system The F-8 Digital Fly-By-Wire DFBW flight research project validated the principal concepts of all-electric flight control systems now used on nearly all modern high-performance aircraft and on military and civilian transports The first flight of the 13-year project was on May 25 1972 with research pilot Gary E Krier at the controls of a modified F-8C Crusader that served as the testbed for the fly-by-wire technologies The project was a joint effort between the NASA Flight Research Center Edwards California now the Dryden Flight Research Center and Langley Research Center It included a total of 211 flights The last flight was December 16 1985 with Dryden research pilot Ed Schneider at the controls The F-8 DFBW system was the forerunner of current fly-by-wire systems used in the space shuttles and on today's military and civil aircraft to make them safer more maneuverable and more efficient Electronic fly-by-wire systems replaced older hydraulic control systems freeing designers to design aircraft with reduced in-flight stability Fly-by-wire systems are safer because of their redundancies They are more maneuverable because computers can command more frequent adjustments than a human pilot can For airliners computerized control ensures a smoother ride than a human pilot alone can provide Digital-fly-by-wire is more efficient because it is lighter and takes up less space than the hydraulic systems it replaced This either reduces the fuel required to fly or increases the number of passengers or pounds of cargo the aircraft can carry Digital fly-by-wire is currently used in a variety of aircraft ranging from F/A-18 fighters to the Boeing 777 The DFBW research program is considered one of the most significant and most successful NASA aeronautical programs since the inception of the agency F-8 aircraft were built originally for the U S Navy by LTV Aerospace of Dallas Texas The aircraft had a wingspan of 35 feet 2 inches; was 54 feet 6 inches long; and was powered by a Pratt Whitney J57 turbojet engine NASA Identifier NIX-ECN-3478 2009-09-23 Glenn Research Center https //www dvidshub net/image/692994 692994 2012-10-10 12 57 WASHINGTON DC US PD-USGov Langley Research Center Images from DoD uploaded by Fæ | ||||
