Keywords: Bildschirmgroesse.svg en Width and height of a screen with given diagonal and aspect ratio de Breite und Höhe eines Bildschirms mit gegebener Diagonale und gegebenem Seitenverhältnis own Benny R 1 12 2008 Source Code This image was created using gnuplot 4 4 3 <pre> Author Benny R reset set terminal svg size 800 600 fixed enhanced font Verdana set encoding iso_8859_1 set style line 1 linetype 1 linewidth 2 linecolor rgb black set style line 2 linetype 1 linewidth 2 linecolor rgb red set style line 3 linetype 1 linewidth 2 linecolor rgb blue set style line 4 linetype 1 linewidth 2 linecolor rgb dark-green set style line 5 linetype 1 linewidth 0 linecolor rgb gray90 set style line 6 linetype 1 linewidth 0 linecolor rgb lemonchiffon w x a b x a / sqrt a 2 + b 2 h x a b x b / sqrt a 2 + b 2 xrange 55 unset key set grid front set xlabel Bildschirmdiagonale in Zoll set xrange 13 xrange set xtics 5 set mxtics 5 set ylabel H\366he und Breite in cm set autoscale y set ytics 5 set mytics 5 set label 1 Breite at 0 65 xrange 2 54 0 68 xrange center front textcolor rgb dark-yellow font Verdana 40 offset 0 1 set label 2 H\366he at 0 85 xrange 2 54 0 25 xrange center front textcolor rgb dark-gray font Verdana 40 offset 0 1 set label 3 5 4 at 0 9 xrange 2 54 w 0 9 xrange 5 0 4 0 left front textcolor rgb black offset 0 2 -0 5 set label 4 5 4 at 0 9 xrange 2 54 h 0 9 xrange 5 0 4 0 right front textcolor rgb black offset -0 2 0 5 set label 5 4 3 at 0 9 xrange 2 54 w 0 9 xrange 4 0 3 0 right front textcolor rgb red offset -0 2 0 5 set label 6 4 3 at 0 9 xrange 2 54 h 0 9 xrange 4 0 3 0 left front textcolor rgb red offset 0 2 -0 5 set label 7 16 10 at 0 9 xrange 2 54 w 0 9 xrange 16 0 10 0 left front textcolor rgb blue offset 0 2 -0 5 set label 8 16 10 at 0 9 xrange 2 54 h 0 9 xrange 16 0 10 0 right front textcolor rgb blue offset -0 2 0 5 set label 9 16 9 at 0 9 xrange 2 54 w 0 9 xrange 16 0 9 0 right front textcolor rgb dark-green offset -0 2 0 5 set label 10 16 9 at 0 9 xrange 2 54 h 0 9 xrange 16 0 9 0 left front textcolor rgb dark-green offset 0 2 -0 5 set output bildschirmgroesse svg plot 2 54 x/sqrt 2 ls 5 with filledcurves x1 \ 2 54 x/sqrt 2 ls 6 with filledcurves x2 \ 2 54 w x 5 0 4 0 ls 1 \ 2 54 h x 5 0 4 0 ls 1 \ 2 54 w x 4 0 3 0 ls 2 \ 2 54 h x 4 0 3 0 ls 2 \ 2 54 w x 16 0 10 0 ls 3 \ 2 54 h x 16 0 10 0 ls 3 \ 2 54 w x 16 0 9 0 ls 4 \ 2 54 h x 16 0 9 0 ls 4 set output set terminal pop reset </pre> Television technology Fernsehtechnik Images with Gnuplot source code |
