| Keywords: Apollo display and keyboard unit (DSKY) used on F-8 DFBW DVIDS683588.jpg en The display and keyboard DSKY unit used on the F-8 Digital Fly-By-Wire DFBW aircraft during Phase I of the fly-by-wire program Warning lights are in the upper left section displays in the upper right and the keyboard is in the lower section The Apollo flight-control system used in Phase I of the DFBW program had been used previously on the Lunar Module and was incredibly reliable The DSKY was one element of the system Also part of the fly-by-wire control system was the inertial platform Both the computer and the inertial platform required a cooling system that used liquid nitrogen to keep the system within temperature limits Should the primary flight control system fail a backup system using three analog computers would automatically take over The F-8 DFBW had no manual backup The F-8 Digital Fly-By-Wire DFBW flight research project validated the principal concepts of all-electric flight control systems now used on nearly all modern high-performance aircraft and on military and civilian transports The first flight of the 13-year project was on May 25 1972 with research pilot Gary E Krier at the controls of a modified F-8C Crusader that served as the testbed for the fly-by-wire technologies The project was a joint effort between the NASA Flight Research Center Edwards California now the Dryden Flight Research Center and Langley Research Center It included a total of 211 flights The last flight was December 16 1985 with Dryden research pilot Ed Schneider at the controls The F-8 DFBW system was the forerunner of current fly-by-wire systems used in the space shuttles and on today's military and civil aircraft to make them safer more maneuverable and more efficient Electronic fly-by-wire systems replaced older hydraulic control systems freeing designers to design aircraft with reduced in-flight stability Fly-by-wire systems are safer because of their redundancies They are more maneuverable because computers can command more frequent adjustments than a human pilot can For airliners computerized control ensures a smoother ride than a human pilot alone can provide Digital-fly-by-wire is more efficient because it is lighter and takes up less space than the hydraulic systems it replaced This either reduces the fuel required to fly or increases the number of passengers or pounds of cargo the aircraft can carry Digital fly-by-wire is currently used in a variety of aircraft ranging from F/A-18 fighters to the Boeing 777 The DFBW research program is considered one of the most significant and most successful NASA aeronautical programs since the inception of the agency F-8 aircraft were built originally for the U S Navy by LTV Aerospace of Dallas Texas The aircraft had a wingspan of 35 feet 2 inches; was 54 feet 6 inches long; and was powered by a Pratt Whitney J57 turbojet engine NASA Identifier NIX-EC96-43408-1 2009-09-23 Glenn Research Center https //www dvidshub net/image/683588 683588 2012-10-10 10 47 WASHINGTON DC US PD-USGov Langley Research Center Images from DoD uploaded by Fæ | ||||
