MAKE A MEME View Large Image 8mm and super8.png Not quite consistent with format specifications from here http //gcmstudio com/filmspecs/filmspecs html Especially the copy of the SMPTE document look trustworthy Film width 7 976 mm +- 0 038 mm Perforation pitch long 4 ...
View Original:8mm and super8.png (1560x1132)
Download: Original    Medium    Small Thumb
Courtesy of:commons.wikimedia.org More Like This
Keywords: 8mm and super8.png Not quite consistent with format specifications from here http //gcmstudio com/filmspecs/filmspecs html Especially the copy of the SMPTE document look trustworthy Film width 7 976 mm +- 0 038 mm Perforation pitch long 4 234 mm +- 0 010 mm Perforation pitch short 4 227 mm +- 0 010 mm Perforation width 0 914 mm +- 0 010 mm Perforation height 1 143 mm +- 0 010 mm Edge to Perforation 0 51 mm +- 0 05 mm Radius of Per fillet 0 13 mm +- 0 03 mm en Super 8 and 8 mm film formats side by side Magnetic stripes are indicated in gray; the wide stripe is the actual sound track the narrow stripe is a balance stripe enabling smooth movement and rolling-up of the film Own Myself Max Smith Error fix Mag stripes by User Janke 2009-06-21 Release all rights into the public domain but an image credit would be nice Sizes taken from various inconsistent sources - if you have better numbers - please drop a note on my source page 8 mm movie cameras
